Pfeiffer hipace 80 ремонт

The Pfeiffer HiPace 80 Series Pump is a complete line of compact yet powerful turbo pumps featuring pumping speeds that range from 10 — 2,000 liters per second. These models are cost-effective and offer flexible installation in any orientation. The proven bearing system provides unrivaled dependability and their sophisticated rotor design makes for higher pumping speeds, higher backing pump compatibility, higher gas throughputs and good compression for light gasses.

Pfeiffer HiPace 80 Features:

Small yet powerful turbopump with a pumping speed of up to 35 l/s for N2
Integrated TC 110 drive electronics
For installation in any orientation
Ideal for dependable systems integration
Extensive accessories expand the range of applications

Pfeiffer Vacuum HiPace 80 Turbo Pump Characteristic:

A&J Vacuum Services offers full repair/service of Pfeiffer Vacuum Pumps, along with all other brands offered on our website. AJVS also services Pfeiffer turbo pumps and rotary vane pumps. Please contact us for information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.

Pfeiffer Vacuum HiPace 80 Turbo Vacuum Pump with TC110 Turbo Pump Controller, DN 40 ISO-KF, PM P03 942 A

Pfeiffer HiPace 80 Technical Data:

Bearing	Hybrid
Compression ratio for Ar	> 1 · 1011
Compression ratio for H2	1.4 · 105
Compression ratio for He	1.3 · 107
Compression ratio for N2	> 1 · 1011
Cooling method, optional	Air/Water
Cooling method, standard	Convection
Cooling water flow	75 l/h
Cooling water flow, max	75 l/h
Cooling water flow, min	75 l/h
Cooling water temperature	5-25 °C \| 41-77 °F \| 278-298 K
Current max.	4,6 A
Electronic drive unit	with TC 110
Flange (in)	DN 40 ISO-KF
Flange (out)	DN 16 ISO-KF/G ¼»
Fore-vacuum max. for N2	22 hPa \| 16.5 Torr \| 22 mbar
Gas throughput at full rotational speed for Ar	0.54 hPa·l/s
Gas throughput at full rotational speed for H2	15.3 hPa·l/s
Gas throughput at full rotational speed for He	2.7 hPa·l/s
Gas throughput at full rotational speed for N2	1.3 hPa·l/s
I/O interfaces	RS-485, Remote
Mounting orientation	Any
Operating voltage: V DC	24 (± 5 %) V DC
Permissible magnetic field max.	3.8 mT
Power consumption max.	110 W
Protection category	IP54
Pumping speed for Ar	30 l/s
Pumping speed for H2	38 l/s
Pumping speed for He	41 l/s
Pumping speed for N2	35 l/s
Rotation speed ± 2 %	90,000 rpm \| 90,000 min-1
Rotation speed variable	50 – 100 %
Run-up time	1.7 min
Sound pressure level	≤48 dB(A)
Ultimate pressure according to PNEUROP
Ultimate pressure without gas ballast	1 · 10-7 hPa \| 7.5 · 10-8 Torr \| 1 · 10-7 mbar
Venting connection	G 1/8″
Weight	2.4 kg \| 5.29 lb

Turbo Pumps
Rotary Vane Pumps
Dry Vacuum Pumps
Leak Detectors

Scroll Dry Pumps
Vacuum Boosters
Diaphragm Dry Pumps

A & J Vacuum Services provides repair service for all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair, Mass Spectrometer repair, Rotary Vane Pump repair, Vacuum Booster repair, and Leak detector repair. Our highly trained technicians have years of experience and guarantee the highest quality service.

We operate at our own full service repair facility in Clifton, NJ. We have invested in state-of-the-art equipment including; complete line of decontamination, cleaning, drying, balancing, vibration analysis and software to minimize failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.

We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.

Repair Steps

Full incoming inspection and run up time check, vibration check, drive inspection.
Full disassembly, decontamination and cleaning.
Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and long pump life.
Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -9 Mbar l/s. Vibrations are analyzed and test data is digitally recorded.

Every pump and instrument is extensively tested for 48 hours. During our final tests, we monitor total pressure, temperature, vibration and noise level utilizing newest testing technologies and techniques specified by OEM. Upon request, we can provide our customers with a pump down graph. Call us for your free repair estimate at 1-973-249-0854.

Overview

Pfeiffer Vacuum HiPace 80 Turbo Vacuum Pump with TC110 Turbo Pump Controller, DN 40 ISO-KF, PMP03942A

Pfeiffer HiPace 80 Overview:

Pfeiffer HiPace 80 Features:

Small yet powerful turbopump with a pumping speed of up to 35 l/s for N2
Integrated TC 110 drive electronics
For installation in any orientation
Ideal for dependable systems integration
Extensive accessories expand the range of applications

Pfeiffer Vacuum HiPace 80 Turbo Pump Characteristic:

Specifications

Pfeiffer Vacuum HiPace 80 Turbo Vacuum Pump with TC110 Turbo Pump Controller, DN 40 ISO-KF, PM P03 942 A

Pfeiffer HiPace 80 Technical Data:

Bearing	Hybrid
Compression ratio for Ar	> 1 · 1011
Compression ratio for H2	1.4 · 105
Compression ratio for He	1.3 · 107
Compression ratio for N2	> 1 · 1011
Cooling method, optional	Air/Water
Cooling method, standard	Convection
Cooling water flow	75 l/h
Cooling water flow, max	75 l/h
Cooling water flow, min	75 l/h
Cooling water temperature	5-25 °C \| 41-77 °F \| 278-298 K
Current max.	4,6 A
Electronic drive unit	with TC 110
Flange (in)	DN 40 ISO-KF
Flange (out)	DN 16 ISO-KF/G ¼»
Fore-vacuum max. for N2	22 hPa \| 16.5 Torr \| 22 mbar
Gas throughput at full rotational speed for Ar	0.54 hPa·l/s
Gas throughput at full rotational speed for H2	15.3 hPa·l/s
Gas throughput at full rotational speed for He	2.7 hPa·l/s
Gas throughput at full rotational speed for N2	1.3 hPa·l/s
I/O interfaces	RS-485, Remote
Mounting orientation	Any
Operating voltage: V DC	24 (± 5 %) V DC
Permissible magnetic field max.	3.8 mT
Power consumption max.	110 W
Protection category	IP54
Pumping speed for Ar	30 l/s
Pumping speed for H2	38 l/s
Pumping speed for He	41 l/s
Pumping speed for N2	35 l/s
Rotation speed ± 2 %	90,000 rpm \| 90,000 min-1
Rotation speed variable	50 – 100 %
Run-up time	1.7 min
Sound pressure level	≤48 dB(A)
Ultimate pressure according to PNEUROP
Ultimate pressure without gas ballast	1 · 10-7 hPa \| 7.5 · 10-8 Torr \| 1 · 10-7 mbar
Venting connection	G 1/8″
Weight	2.4 kg \| 5.29 lb

Manuals

MFR Brochures

AJVS Brochures

Spare Parts

Accessories

Service & Repair

Turbo Pumps
Rotary Vane Pumps
Dry Vacuum Pumps
Leak Detectors

Scroll Dry Pumps
Vacuum Boosters
Diaphragm Dry Pumps

We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.

Repair Steps

Full incoming inspection and run up time check, vibration check, drive inspection.
Full disassembly, decontamination and cleaning.
Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and long pump life.
Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -9 Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
